New Product Drawer Slide Hardware Undermount

1 / 5

New Product Drawer Slide Hardware Undermount

Still deciding? Get samples of $ !

Request Sample

Send Inquiry

Product Description

Basic Info.

Structure

Three Members

Slide Type

Soft Close/Push Open

Condition

New

Length

9''-24''

Application

Commercial and Domestic Drawers

Load

35kg

Times of Use

50,000

Features

Smooth and Silent

Transport Package

Paper Carton

Specification

American & European style

Origin

China

HS Code

8302420000

Production Capacity

80 Container/Month

Product Description

Application: Suitable for commercial and domestic drawer

Features: Built-in Buffer, constant speed deceleration and automatic closing, soft, smooth and silent shutdown at a constant speed, easy to disassemble, 2D adjustable drawer height 0-3mm, 3D up, down, left, and right can be adjusted 0-3mm.

Load Capacity: 35kg, long life, more than 50,000 times of use

Material: Galvanized sheet, 1.8mm*1.4mm*1.0mm.

Product number	Series Length	Drawer Length(L)	Internal depth of cabinet (Min external)	Inside the cabinet deep (Built-in min)	Packing Unit (Set/Carton)
BS901-HT-9''	229mm	229mm	266mm	286mm	8
BS901-HT-12''	305mm	305mm	342mm	362mm	8
BS901-HT-15''	381mm	381mm	418mm	438mm	8
BS901-HT-18''	457mm	457mm	494mm	514mm	8
BS901-HT-21''	533mm	533mm	570mm	590mm	8

* PS: The drawer side panel is 18mm model

Product number	Series Length	Drawer Length(L)	Internal depth of cabinet (Min external)	Inside the cabinet deep (Built-in min)	Packing Unit (Set/Carton)
BS804-HH-10''	250mm	250mm	269mm	269mm+X	10
BS804-HH-12''	300mm	300mm	319mm	319mm+X	10
BS804-HH-14''	350mm	350mm	369mm	369mm+X	10
BS804-HH-16''	400mm	400mm	419mm	419mm+X	10
BS804-HH-18''	450mm	450mm	469mm	469mm+X	10
BS804-HH-20''	500mm	500mm	519mm	519mm+X	10
BS804-HH-22''	550mm	550mm	569mm	569mm+X	10
BS804-HH-24''	600mm	600mm	619mm	619mm+X	10

* PS: The drawer side panel is 18mm model; X: Panel thickness

Product Display

Frequently Asked Questions

How to get samples?

Yes, you can get free samples to check the quality. However, you need to take care of freight costs. Options: 1) Send by your tracking NO. 2) Arrange pick-up. 3) Pay for freight cost (approx. 1 week delivery, recommended).

What is the MOQ?

It depends on different items. Normally for slides, it is 500 sets, or an amount more than $5000.

How long is the delivery time?

15-30 days after receiving the deposit. If consolidating many items, shipment will be around 45 days.

What is the payment term?

EXW, FOB, CNF. It depends on customers' requirements.

What is the loading capacity for 20ft?

Normally it is 22 tons, but to the United States it is around 17 Tons.

Is it possible to mix different items?

Yes, you can send your requirement and ask for a quotation from us.
